VALUE VTB-CB1R copper tube bender (HVACR) - for tubes dia. ¼" (6mm), 5/16"(8mm), 3/8" (10mm), 1/2" (12mm), 5/8" (16mm), 3/4" (19mm), 7/8" (22mm)
- 7 tube sizes can be easily selected using a single selector switch
- ergonomic design for easy and joint-friendly operation
- easy tube extraction at the end of the bending operation
Bending/curving copper tubing for the refrigeration and air conditioning (HVACR) industry can be difficult, especially for large diameter tubing, and requires a lot of time and attention to get the job done professionally.
Furthermore, removing the tube from a traditional mandrel is often a delicate operation.
The VALUE VTB-CB1R copper tube bending machine saves time and labour, making the job much easier and more precise.
Suitable for 1/4" (6 mm), 5/16" (8 mm), 3/8" (10 mm), 1/2" (12 mm), 5/8" (16 mm), 3/4" (19 mm), 7/8" (22 mm) copper tubing.
By simply pressing the lever on the bender, the tube can be bent to any desired angle. When bending is complete, the baffle automatically ejects the tube as the tool resets, helping you to remove the tube effortlessly.
Features:
- bending angle: 0° to 90°
- suitable for annealed copper pipes
- dimensions: 325 x 250 x 180 mm
- weight: 3.4 kg tool only, 4.4 kg including VTBRK reverse bending kit
Supplied in plastic case.
NOTE: the VTBRK kit for reverse bending is inlcuded in the package; with the kit it is possible to bend the copper tube in the opposite direction to that of the battery bender (i.e. outwards).
