MP-series – Detectors for connection to MPU/SPU/SPLS with semiconductor sensor (SC)
SAMON code: 38-420
Sensor for installation in engine rooms, compressor rooms and any other application where gases are used or stored.
The MP series sensors have been designed specifically for the MPU / SPU
Measuring ranges and alarm levels:
The alarm levels are always set on the control unit.
Appropriate measuring ranges and alarms depend on the environment in which the detectors are installed and the type of gas to be detected
Compliant with F-gas 517/2014 regulations; EN 378:2008; EN 14624 and JRA4068
Features:
0-4,000 ppm
Requires connection to MPU2C, MPU4C, MPU6C and SPU control units
Power supply from the control unit
Waterproof and anti-corrosion housing for installation in industrial environments
Ambient temperature -40°C +50°C
Humidity 0-95% Rh (non-condensing)
IP54 protection
NOTE:
Sensors are consumable parts, estimated life 5 years. Simple replacement. DT300 calibration method. Annual maintenance.
The alarm level is set on the control unit, usually during start-up
